WLD-TEC Fuego SCS basic RF
Description
The Laboratory Gas Burner with Embedded Radio Technology. Fuego SCS Basic RF - Safety laboratory gas burner with wireless radio foot pedal.
The Fuego SCS Basic RF represents a new standard among laboratory gas burners. With its innovative design this laboratorygas burner is suitable for all flame related applications in the laboratory.
Simple and Safe Operation
The Fuego SCS basic RF can be operated with a wireless foot pedal or the button function. Three programs are available: flexible start-stop functions and the conventional foot pedal operation for short flame sterilization. The Fuego SCS basic RF is also suitable for connection to the fully automated innoculation loop carrousel autoloop Pro.
Flame Sterilizing with Button Function
WLD-TEC offers an additional alternative for safe flame sterilizing. With the button function the flame can be started and stopped easily by pushing the function knob.
Everything inside
The Fuego SCS basic RF represents the complete system of the new Wireless-Series “RF“. The modern radio operation is already integrated in the safety laboratory gas burner.
Top Rate Safety
The Safety Control System SCS demonstrates state-of-the-art safety technology which constantly analyzes potential hazards and, if necessary, initiates safety measures, such as an interruption of the gas supply. In addition to the ignition and flame control function and the overheating protection, the new safety concept also features continuous burner head control (BHC). BHC unfailingly identifies burner head clogging by liquids or solid substances and ensures the correct assembly of the burner head. Exceptional passive safety features: After prolonged use, the residual heat display will signal that the burner head is still hot in order to protect the user from burns.
Modern Design
The unique shape is eye-catching. The Fuego SCS basic RF is extremely space-saving. Measurements: 103 x 49 x 130 mm (w x h x d). The low profile body facilitates ergonomic operation; the streamlined design reduces air flow disturbances in a clean room workbench to a minimum. Moreover, the Fuego SCS basic RF is very easy to clean - a laboratory gas burner without grooves and rough edges. Clogging is not an issue. Spilled liquids simply escape through an integrated drain while solid substances can easily be removed by opening the burner shaft. It is even possible to dismantle the individual components of the removable burner head for in-depth cleaning. With the DualKnob for adjusting gas and air flow, the flame can be precisely regulated.
Another Plus
Excellent energy efficiency reduces the gas consumption. This increases the burning time when gas cartridges are used.
Robust
Fabricated entirely of stainless steel and with fireproof controls the Fuego SCS basic RF can withstand extreme lab conditions.
Fuego SCS basic - Ideal for use in cleanroom workbenches and laboratories.
Technical Details
| Technology | Microprocessor, illuminated graphic display with acoustic signals as operating aids |
| Programs | |
| Foot pedal: | Standard (flame during pressed foot pedal) Start-Stop with timer, 60 min |
| Button: | Start-Stop with timer, 60 min |
| Safety features | |
| Safety Control System (SCS) with gas safety cut off: | ignition and flame control, temperature monitor burner head clogging and assembly monitor (BHC) automatic unit switch off after 4h residual heat display |
| Gas supply and consumption | |
| Gas connection: | 1/4” left with gas filter |
| Gas types: | II2ELL3B/P: natural gas E/LL,18 - 25 mbar liquid gas, 47,5 - 57,5 mbar |
| Connected load: | 70 g/h liquid gas; 95 l/h natural gas (LL) |
| Continuous cartridge operation: |
|
| Temperatures | |
| Flame temperature: |
|
| Temperature threshold level: | 1 kW liquid gas, 1kW natural gas |
| Electrical | |
| Power consumption: | 2 VA (stand by max. 0.1 VA) |
| Power connection: | 100-240V / 50/60Hz / max. 0.3 A; 9V DC / 1.3A Level 6 (stand by power consumption max. 0.1W) |
| Mechanical | |
| Casing and operating controls: | stainless steel / glass, UV and solvent resistant |
| Burner head: | removable and decomposable, stainless steel |
| Cover of burner shaft: | Ø 23 mm, with drains |
| Measurements (w x h x d): | 103 x 49 x 130 mm |
| Weight: | 700 g |
| Radio Frequency System | |
| Range: | Range: 2 - 5 m |
| Frequency: | 2.4 GHz |
| Channels: | 253 |
| Batteries foot pedal: | 2 x AA (Mignon) |
| Life time batteries (foot pedal): | approx. 2000 hours (operation 8 hours per day: > 1 year) |
| Licenses | |
| DIN-DVGW Reg.-No.: | NG-2211AS0167 |
| CE: | EN 61326-1, EN 61010-1, EN 61010-2-010, EN 301489, EN 300440-1, EN 300440-2 |
| EU guidelines: | 2014/30/EU, 2014/35/EU, 2011/65/EU, 2014/53/EU (RED) |
